Connector Description
JPW2–JPW4
4-pin +12 V Power Connectors for NVMe Backplane, AIOM Adapter and
Internal PCIe Riser Card
JTPM1 Trusted Platform Module/Port 80 Connector
M.2-H1, M.2-H2 M.2 NVMe or SATA SSDs
Note: Jumpers, connectors, switches, and LED indicators that are not described in these
tables are for manufacturing testing purposes only, and are not covered in this manual.
Motherboard Features
Motherboard Features
CPU
l
Single AMD EPYC™ 9005 Series processor processors in Socket SP5
Memory
l
Up to 3 TB registered ECC DDR5 memory with speeds of up to 6400 MT/s in 12 memory slots
Note: Memory speed support depends on the processor used in the system.
DIMM Size
l
Up to 256 GB
Chipset
l
System on Chip (SoC)
Expansion Slots
l
Two M.2 PCIe 5.0 x4 connectors in the 22110/2280 form factors
l
One PCIe 4.0 x8 4C customized 124-pin SLIM COOL EDGE connector (for the I/O module)
Input/Output
l
Eight PCIe 5.0 x8 MCIO connectors
l
One PCIe 5.0/SATA3 p14-x8 MCIO hybrid port connector
Network
l
ATEN IPMI from ASPEED BMC for one Gigabit RJ45 port
l
AIOM1/AIOM2 through cable to MCIO connectors
Graphics
l
Graphics controller through ASPEED AST2600 BMC
14
H14SST-GE: Introduction
