Connector Description
MH4, MH22 Thumbscrews for mounting the motherboard
P1_NVMe0/1, PCIe 1A
P1_SATA8-15
NVMe Ports 0/1, P1_SATA 8-15, supported by CPU1
P1_NVMe2/3, PCIe 1B
P1_SATA0-7
NVMe Ports 2/3, P1_SATA 0-7, supported by CPU1
P1_NVMe4/5, PCIe 2A NVMe Ports 4/5, supported by CPU1
P1_NVMe6/7, PCIe 2B NVMe Ports 6/7, supported by CPU1
P1_NVMe8/9, PCIe 3A NVMe Ports 8/9, XGMI, supported by CPU1
P1_NVMe10/11, PCIe
3B
NVMe Ports 10/11, XGMI, supported by CPU1
P2_NVMe0/1, PCIe 4A
P2_SATA0-7
NVMe Ports 0/1, P1_SATA 0-7, supported by CPU2
P2_NVMe2/3, PCIe 4B
P2_SATA8-15
NVMe Ports 2/3, P1_SATA 8-15, supported by CPU2
P2_NVMe4/5, PCIe 5A NVMe Ports 4.5, supported by CPU2
P2_NVMe6/7, PCIe 5B NVMe Ports 6/7, supported by CPU2
P2_NVMe8/9, PCIe 6A NVMe Ports 8/9, supported by CPU2
P2_NVMe10/11, PCIe
6B
NVMe Ports10/11, supported by CPU2
P2_NVMe12/13,
PCIe7A
NVMe Ports 12/13, XGMI, supported by CPU2
P2_NVMe14/15,
PCIe7B
NVMe Ports 14/15, XGMI, supported by CPU2
P1 SLOT1 PCIe 5.0 x16 slot, CPU1
P2 SLOT1 PCIe 5.0 x16 slot, CPU2
PSU1, PSU2 Power Supply Module Connectors
14
H14DSH: Introduction
