Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open (Normal)
LED Description Status
LEDBMC BMC Heartbeat LED
Green Blinking: BMC Normal
Green Blinking Fast: BMC Initializing
Connector Description
BT1 Onboard Battery
FAN1–FAN8 6-pin Fan Headers
FAN9, FANSTBY 4-pin Fan Headers
JAIOM
Supermicro Advanced Input/Output Module (AIOM) PCIe 5.0 x16
Connector
JBPNI2C1, 2 4-pin BMC External I²C Headers for backplane
JNVI2C1, 2 4-pin I²C Headers for NVMe Backplane Hot-swap Support
JRSI2C1 4-pin BMC External I²C Header for Riser Card
JFP1 Front Control Panel Connector
JIO1 Onboard VGA/USB/NIC I/O Module Connector
JIPMB1 4-pin External BMC I²C Header
JL1 Chassis Intrusion Header
JNCSI1 NC-SI Connector
JPW1–12 12V 8-pin GPU/BPN/AOC Power Connector
JPW13 5 V/ 12 V Backplane Power Connector
JSEN2
4-pin BMC External I²C Header for Liquid Cooling Module leak detection
sensor
JTPM1 Trusted Platform Module/Port 80 Connector
JUSB1 Front Panel USB Connector
M.2-C1, M.2-C2 M.2 PCIe Interfaces (NVMe only)
13
