For a detailed diagram of the CARAM5- M motherboard, see the layout under "Quick
Reference" on page 11.
Watchdog Timer
Jumper Settings
Jumper Setting Definition
Pins 1–2 Reset (Default)
Pins 2–3 NMI
Open Disabled
LED Indicators
For information about the LED indicators on the CARAM5-M motherboard, refer to the following
content.
Power Fail/Fan Fail LED
LED6 is the power and fan fail LED. Refer to the table below for the LED status.
For a detailed diagram of the CARAM5- M motherboard, see the layout under "Quick
Reference" on page 11.
Power Fail/Fan Fail LED
LED Indicator
Pin# Definition
Blinking Red Power Fail or Fan Fail
Solid Red Overheat
Onboard Power LED
An Onboard Power LED is located on the CARAM5-M motherboard. When this LED is on, the
system is on. Be sure to turn off the system and unplug the power cord before removing or
installing components.
For a detailed diagram of the CARAM5- M motherboard, see the layout under "Quick
Reference" on page 11.
Onboard Power LED Indicator
LED Color Definition
Off System Power Off (power cable not connected)
Green System Power On
51
CARAM5-M: Component Installation
