ATX Power 24-pin Connector
Pin Definitions: 24 Total
Pin# Definition Pin# Definition
2 +3.3 V 14 -12 V
3 Ground 15 Ground
4 +5 V 16 PS_ON
5 Ground 17 Ground
6 +5 V 18 Ground
7 Ground 19 Ground
8 PWR_OK 20 Res (NC)
9 5 VSB 21 +5 V
10 +12 V 22 +5 V
11 +12 V 23 +5 V
12 +3.3 V 24 Ground
Headers and Connections
For information about the headers on the CARAM5-M motherboard, refer to the following
content.
Audio Front Panel Header
A 10-pin audio header (AUDIO FP) located on the motherboard allows you to use the onboard
sound chip (ALC888S) for the audio function. Connect an audio cable to this header to use this
feature. Refer to the table below for pin definitions.
For a detailed diagram of the CARAM5- M motherboard, see the layout under "Quick
Reference" on page 11.
Audio Header
Pin Definitions: 10 Total
Pin# Definition Pin# Definition
1 Microphone_Left 2 Audio_Ground
3 Microphone_Right 4 Audio_Detect
5 Line_2_Right 6 Ground
45
