2.6 Connections, Jumpers, and LEDs
Refer to the following sections for information about connections, jumpers, and LEDs for the
CARAM5-M motherboard.
Power Supply and Power Connections
For information about the power supply and power connections of the CARAM5- M
motherboard, refer to the following content.
Power Supply
As with all computer products, a stable power source is necessary for proper and reliable
operation. It is even more important for processors that have high CPU clock rates where noisy
power transmission is present.
There are two 12 V power connectors (JPW1 and JPW2) on the CARAM5-M motherboard.
Power Connectors
12V 8-pin Auxiliary Power Connector (JPW2)
JPW2 is an 8-pin ATX power input to provide auxiliary power to the processor. Refer to the
table below for pin definitions.
12 V 8-pin Power Connector
Pin Definitions: Eight Total
Pin# Definition Pin# Definition
1 Ground 5 +12 V
2 Ground 6 +12 V
3 Ground 7 +12 V
4 Ground 8 +12 V
Main Power Supply Connector (JPW1)
The primary power supply connector (JPW1) is an ATX power connector that the power supply
plugs directly into.
ATX Power 24-pin Connector
Pin Definitions: 24 Total
Pin# Definition Pin# Definition
1 +3.3 V 13 +3.3 V
44
CARAM5-M: Component Installation
