Chapter 5: Optional Components Chapter 5: Optional Components

Chapter 5

Optional Components

This chapter describes optional system components and installation procedures.

5.1 TPM Security Module

SPI capable TPM 2.0 (or 1.2) with Inneon 9670 controller, Horizontal form factor

The JTPM1 header is used to connect a Trusted Platform Module (TPM). A TPM is a

security device that supports encryption and authentication in storage drives. It enables the

motherboard to deny access if the TPM associated with the storage drive is not installed in

the system.

Details and installation procedures are at:

http://www.supermicro.com/manuals/other/TPM.pdf.

5.2 Intel Virtual RAID on CPU (VROC)

Intel

Virtual RAID on CPU (Intel VROC) is an enterprise RAID solution for NVMe SSDs

directly attached to Intel Xeon Scalable processors. Intel Volume Management Device (VMD)

is an integrated controller inside the CPU PCIe root complex.

• A single processor supports up to 12 NVMe SSDs and up to 6 RAID arrays.

• A dual processor system supports up to 24 NVMe SSDs and 12 RAID arrays.

Stripe sizes are 4K, 8K, 16K, 32K, 64K, 128K.

Requirements and Restrictions

•

Intel VROC is only available when the system is congured for UEFI boot mode.

• To enable the mdadm command and support for RSTe, install the patch from

• Linux: https://downloadcenter.intel.com/download/28158/Intel-Virtual-RAID-on-CPU-In-

tel-VROC-and-Intel-Rapid-Storage-Technology-enterprise-Intel-RSTe-Driver-for-Linux-

• Windows: https://downloadcenter.intel.com/download/28108/Intel-Virtual-RAID-on-

CPU-Intel-VROC-and-Intel-Rapid-Storage-Technology-enterprise-Intel-RSTe-Driver-for-

Windows-

• VROC requires a software license or a hardware key inserted on the motherboard, and the

appropriate processor’s Virtual Management Devices must be enabled in the BIOS setup.

• Intel VROC is not compatible with secure boot. This feature must be disabled.

• When creating bootable OS RAID1 devices, you must have both devices on the same

CPU, and a VMD on that CPU.

• Spanning drives when creating RAID devices is not recommended due to performance

issues, even though it is supported.

Supported SSDs and Operating Sytems

To see the latest support information: https://www.intel.com/content/www/us/en/support/

articles/000030310/memory-and-storage/ssd-software.html
