Chapter 2: Installation and Setup Chapter 2: Installation and Setup

Max Series CPUs

Memory Population, 32 DIMM Slots

CPUs/DIMMs Slots

1 CPU & 1 DIMM A1 or E1

1 CPU & 2 DIMMs

A1, G1 or

C1, E1

1 CPU & 4 DIMMs

A1, C1, E1, G1

1 CPU & 8 DIMMs

A1, B1, C1, D1, E1, F1, G1, H1

1 CPU & 16 DIMMs

A1, A2, B1, B2, C1, C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

2 CPUs & 2 DIMMs

CPU1: A1; CPU2: A1 or

CPU1: E1; CPU2: E1

2 CPUs & 4 DIMMs

CPU1: A1, G1; CPU2: A1, G1 or

CPU1: C1, E1; CPU2: C1, E1

2 CPUs & 8 DIMMs

CPU1: A1, C1, E1, G1

CPU2: A1, C1, E1, G1

2 CPUs & 16 DIMMs

CPU1: A1, B1, C1. D1, E1, F1, G1, H1

CPU2: A1, B1, C1. D1, E1, F1, G1, H1

2 CPUs & 32 DIMMs

CPU1: A1, A2, B1, B2, C1. C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

CPU2: A1, A2, B1, B2, C1. C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

Notes:

• Max Series (HBM) CPU supports 1DPC (4800 MT/s) / 2DPC (4400 MT/s) to optimize

the memory bandwidth. Max Series (HBM) CPU supports 1, 2, 4, 8, or 16 DIMMs in Flat

Mode as well as Cache Mode, and 0 DIMMs in HBM-Only mode. HBM-Only mode runs

exclusively using HBM memory.

• SPR+HBM supports 4, 8, or 16 DIMMs in all modes (Flat / Cached and Quadrant / SNC4)

4 DIMMs -> populate 1 DIMM/iMC

8 DIMMs -> populate 1 DIMM/Channel, 2 DIMM/iMC

16 DIMMs -> populate 1 DIMM/Channel, 4 DIMM/iMC

• All other congurations not listed above are not supported.

• For 2S design, each socket has to be populated identically.

XCC, MCC, LCC CPUs

Use the DIMM slots listed below for memory modules. This memory population table is based

on guidelines provided by Intel to support Supermicro motherboards.

Memory Population, 32 DIMM Slots

CPUs/DIMMs DIMM Slots

1 CPU & 1 DIMM A1 or B1 or E1 or F1

1 CPU & 2 DIMMs

A1, G1 or

C1, E1

1 CPU & 4 DIMMs A1, C1, E1, G1

1 CPU & 6 DIMM

A1, C1, D1, E1, F1, G1 or

A1, B1, C1, E1, G1, H1 or

B1, C1, D1, E1, F1, H1 or

A1, B1, D1, F1, G1, H1

1 CPU & 8 DIMMs A1, B1, C1, D1, E1, F1, G1, H1

1 CPU & 12 DIMMs

A1, A2, B1, C1, C2, D1, E1, E2, F1, G1, G2, H1 or

A1, B1, B2, C1, D1, D2, E1, F1, F2, G1, H1, H2

1 CPU & 16 DIMMs A1, A2, B1, B2, C1, C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

2 CPUs & 2 DIMMs

CPU1 A1, and CPU2: A1 or

CPU1 B1, and CPU2: B1 or

CPU1 E1, and CPU2: E1 or

CPU1 F1, and CPU2: F1

2 CPUs & 4 DIMMs

CPU1 A1, G1 and CPU2: A1, G1 or

CPU1 C1, E1 and CPU2: C1, E1

2 CPUs & 8 DIMMs CPU1: A1, C1, E1, G1, and CPU2: A1, C1, E1, G1

2 CPUs & 10 DIMMs CPU1: A1, C1, D1, E1, F1, G1, and CPU2: A1, C1, E1, G1

2 CPUs & 12 DIMMs

CPU1: A1, C1, D1, E1, F1, G1 and CPU2: A1, C1, D1, E1, F1, G1 or

CPU1: A1, B1, C1, E1, G1, H1 and CPU2: A1, B1, C1, E1, G1, H1 or

CPU1: B1, C1, D1, E1, F1, H1 and CPU2: B1, C1, D1, E1, F1, H1 or

CPU1: A1, B1, D1, F1, G1, H1 and CPU2: A1, B1, D1, F1, G1, H1

2 CPUs & 16 DIMMs CPU1: A1, B1, C1. D1, E1, F1, G1, H1, and CPU2: A1, B1, C1. D1, E1, F1, G1, H1

2 CPUs & 22 DIMMs

CPU1: A1, A2, B1, B2, C1. C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

CPU2: A1, C1. D1, E1, F1, G1

2 CPUs & 24 DIMMs

CPU1: A1, A2, B1, B2, C1. C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

CPU2: A1, B1, C1. D1, E1, F1, G1, H1

2 CPUs & 32 DIMMs

CPU1: A1, A2, B1, B2, C1. C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

CPU2: A1, A2, B1, B2, C1. C2, D1, D2, E1, E2, F1, F2, G1, G2, H1, H2

*Unbalanced, not recommended.

• Other Intel validated memory congurations are supported, although they may not provide

optimal performance. See Intel documentation for more information.

• Must have at least one DIMM per CPU.
