LVDS Connector
Pin Definitions: 40 Total
Pin# Description Pin# Descritption
29 LVDSB D0N 30 LVDSB D0P
31 LVDSB D1N 32 LVDSB D1P
33 LVDSB D2N 34 LVDSB D2P
35 LVDSB CLKN 36 LVDSB CLKP
37 LVDSB D3N 38 LVDSB D3P
39 GND 40 GND
M.2 Slots
The motherboard has three M.2 slots (JMD1, JMD2, JMD3). M.2 was formerly known as Next
Generation Form Factor (NGFF) and serves to replace mini PCIe. M.2 allows for a variety of
card sizes, increased functionality, and spatial efficiency. The M.2 M- Key slot on the
motherboard supports SATA 3.0/PCIe 3.0 Gen 3 x1 devices in a 2242/2280 form factor. The
M.2 B- Key slot supports Nano SIM/5G/PCIe x1/SATA 3.0/USB 3.0/USB 2.0 devices in a
2242/2280/3052 form factor. The M.2 E-Key slot supports PCIe x1/ USB 2.0/CNVi devices in a
2230 form factor. For B-Key 3052 support, use an MCP-410-00021-0N bracket.
For a detailed diagram of the A4SAN-H/-E/-L/-WOHS motherboard, see the layout under
"Quick Reference" on page 11.
M.2 B-Key
Pin Definitions: 75 Total
Pin# Definition Pin# Definition
1 No Connection 2 P3V3SB
3 GND 4 P3V3SB
5 GND 6 FULL_CARD_POWER_OFF# (PU to P1V8SB only)
7 USB_D+ 8 W_DISABLE1#(PU to P3V3SB only)
9 USB_D- 10 LED_N
11 GND 12 KEY B
13 KEY B 14 KEY B
15 KEY B 16 KEY B
17 KEY B 18 KEY B
19 KEY B 20 PCIE_DIS
47
A4SAN-H/-E/-L/-WOHS: Component Installation
