GPIO Header
Pin Definitions: 10 Total
Pin# Description Pin# Description
1 P3V3SB 2 GND
3 GP_P3V3_GP0 4 GP_P3V3_GP4
5 GP_P3V3_GP1 6 GP_P3V3_GP5
7 GP_P3V3_GP2 8 GP_P3V3_GP6
9 GP_P3V3_GP3 10 GP_P3V3_GP7
Low Voltage Differential Signaling
LVDS1 on the bottom side of the motherboard is the LVDS connector. Low-voltage differential
signaling (LVDS) is a high-speed digital interface that operates at low power. It is a type of
connection that is mostly used with monitors.
For a detailed diagram of the A4SAN-H/-E/-L/-WOHS motherboard, see the layout under
"Quick Reference" on page 11.
LVDS Connector
Pin Definitions: 40 Total
Pin# Description Pin# Descritption
1 12 V 2 12 V
3 12 V 4 12 V
5 12 V 6 GND
7 3.3/5 V 8 GND
9 LCDVCC 10 LCDVCC
11 DDC CLK 12 DDC DATA
13 BKLTCTL 14 PVCCEN
15 BKLTEN 16 GND
17 LVDSA D0N 18 LVDSA D0P
19 LVDSA D1N 20 LVDSA D1P
21 LVDSA D2N 22 LVDSA D2P
23 LVDSA CLKN 24 LVDSA CLKP
25 LVDSA D3N 26 LVDSA D3P
27 GND 28 GND
