COM Headers
There are four COM ports: JCOM1 with support for two RS232/422/485 connections and
JCOM2 with support for two RS232 connections. The manufacturer of the header is ACES
Electronics, MPN 50419- 02001. The mapping plug header for cable assembly is 50420-
020KHK0-001. See the pin definition tables of the onboard headers and D-SUB of CBL-CDAT-
0665. Refer to the corresponding table based on design requirements.
For a detailed diagram of the A4SAN-H/-E/-L/-WOHS motherboard, see the layout under
"Quick Reference" on page 11.
42
A4SAN-H/-E/-L/-WOHS: Component Installation
