4 Mechanical Mounting User Manual
In case the installation site is a level surface, mount the inverter to the bracket to
meet the mounting angle requirements, as shown in the figure below.
Take the following items into account when designing the bracket scheme:
•
Consider onsite climate conditions and take anti-snow and anti-rain measures
if necessary.
•
Ensure that the waterproof connectors are at least 550 mm higher than the
ground surface.
•
Bind the cables at the positions 300~350 mm away from the DC connector, AC
waterproof terminal, and communication waterproof terminal.
•
The various waterproof terminals should be tightened with the torque specified
in this manual to ensure that they are securely sealed.
Contact SUNGORW if you have any question.
24
