No. Name
A Wiring copper bar
B Low voltage incoming line sealing plate
C Tower type protective coil
D Cable clamp
E Single core cable
F Container base
G Single core double splicing cable
H U-shaped cable clamp
I Three core cable
J Three core double splicing cable
WARNING
• Incorrect connection sequence may cause fire. Pay maximum attention to the
connection sequence.
• Ensure the firmness of the cable connection. Poor connection or oxidation of the
surface may cause over-heating or fire.
• During the wiring process, brute force operation is not allowed, and insulation
protection should be taken to ensure that the safety regulations meet the
requirements.
• Backfilling should be carried out after the low-voltage cable wiring is completed.
NOTICE
• Long bolts may affect the insulation and may cause short circuit.
• Remove the heat-shrink tubing between the cable lug and the copper bar if
necessary. Poor contact or over-heating may follow if otherwise.
• Low voltage incoming cables shall be Class A insulated cables with a temperature
resistance of 90 ℃.
• Low voltage incoming cables need to pass through cable clamps, tower type
protective coils, and connect to wiring terminals from the bottom.
• Foundation design needs to consider sufficient space for low-voltage cable trenches.
Ensure that operators can enter and secure cable clamps.
6.5.2 Wiring Step
System Manual6 Electrical Installation
40
