5.4 Installing the Drain Valve/Oil-Water Separator
There are two design schemes at the bottom of MV Station. Drain valve or oil-water
separator can be installed according to customized requirements.
NOTICE
For ease of installation, it is recommended to install the drain valve or oil-water separator
before hoisting the MV Station to the installation position.
NOTICE
During the installation of the oil-water separator, first remove the two plastic plugs of the
equipment. Then, install the oil-water separator on one of the ports, and seal the other
port with a stainless steel plug.
5.4.1 Installing the Drain Valve(Optional)
Prerequisite
Installation Parts
Before installing the drain valve, the required parts:
• Connector(in the scope of delivery)
• Drain valve(in the scope of delivery)
• Oil pipe (beyond the scope of delivery)
Installation Methods
Step 1 Screw the connector into the mounting hole at the bottom of the MV Station.
Step 2 Install the drain valve on the connector.
Step 3 (Optional operation) Connect the oil pipe to the drain valve.
--End
Precautions
• If the oil pipe is connected, the drain valve needs to be opened.
• If the oil pipe is not connected, the drain valve needs to be closed.
System Manual5 Mechanical Installation
28
