Perform the external grounding according to on-site situation and instructions of the plant
staff.
The grounding resistance should be no more than 4Ω.
The grounding resistance should be determined according to local standards and
regulations.
WARNING
The country-specific regulations and standards must be observed at all times!
6.5 LV Connection
Prerequisite
LV wiring terminals are located at the lower part of the LV cabinet, There are wiring
terminals distributed on the left and right sides of the LV cabinet. The terminal structure is
shown in the figure below.
6.5.1 Cable Layout
When the upstream inverter is SG320HX/SG350HX series, there are four ways to connect
the LV side cables.
System Manual 6 Electrical Installation
39
