NOTICE
Do not plant any trees near the MV Station installation site to prevent the damage of the
MV Station caused by tree leaves or stems.
5.4 Installing the Drain Valve/Oil-Water Separator
There are two design schemes at the bottom of MV Station. Drain valve or oil-water
separator can be installed according to customized requirements.
NOTICE
For ease of installation, it is recommended to install the drain valve or oil-water separator
before hoisting the MV Station to the installation position.
NOTICE
During the installation of the oil-water separator, first remove the two plastic plugs of the
equipment. Then, install the oil-water separator on one of the ports, and seal the other
port with a stainless steel plug.
5.4.1 Installing the Drain Valve(Optional)
Prerequisite
Installation Parts
Before installing the drain valve, the required parts:
• Connector(in the scope of delivery)
• Drain valve(in the scope of delivery)
• Oil pipe (beyond the scope of delivery)
Installation Methods
Step 1 Screw the connector into the mounting hole at the bottom of the MV Station.
Step 2 Install the drain valve on the connector.
Step 3 (Optional operation) Connect the oil pipe to the drain valve.
System Manual 5 Mechanical Installation
29
