8
LOAD LEVEL GUIDE & TEMPERATURE GUIDE - MODELS C(T)(L)(H)R
LOAD LEVEL & TEMPERATURE GUIDE - MODELS C(T)(L)(H)R
>> FOLLOW THESE PRODUCT PLACEMENT GUIDELINES TO
MAINTAIN DESIRED PRODUCT TEMPERATURES.
>> FRONT TO REAR PRODUCT TEMPS ARE ESTIMATES ONLY.
>> NOTES CORRESPOND WITH ILLUSTRATIONS SHOWN.
1. ALLOW AT LEAST 1” SPACE BETWEEN PRODUCT AND
ITS SHELF ABOVE.
2. AT CASE REAR, ALLOW AT LEAST 1” SPACE BETWEEN
PRODUCT AND REAR PERFORATED PLENUM.
3. DO NOT BLOCK 1 1/4” AIR RETURN OPENING WITH PRODUCT.
>> IF YOU ARE UNABLE TO MAINTAIN DESIRED PRODUCT
TEMPERATURES, SEE TROUBLESHOOTING SECTION IN MANUAL.
37 °F TO 41 °F
PRODUCT AT
CASE FRONT
33 °F To 37 °F
PRODUCT AT
CASE REAR
MODEL C33R SHOWN ABOVE. CASE IS PARTIALLY DISASSEMBLED, CROSS SECTIONED
AND PACKAGED PRODUCT LADEN FOR ILLUSTRATIVE PURPOSES ONLY.
HEADER
PACKAGED
PRODUCT
ILLUSTRATION
PRODUCT
TEMPERATURE
RANGE SHOWN
AT RIGHT.
1
2
3
