CASE REMOVAL FROM SKID / POSITIONING / FORK LIFT / J-BAR or DOLLY

J-Bar Lift Tabs

Remove Case From Skid

Fork Lift

• To lift case up for lift-truck forks to slide into position,

place J-bar, pry bar or dolly under J-Bar lift tabs

(location shown below).

• Note: REAR lift tabs are extended beyond base

frame bolts (to allow greater access).

• Raise case up to allow forks to slide under rails.

• Insert forks under rails.

• Make certain case is well-supported on forks.

Move case to desired location. Lower in place.

• Note: Illustration shown may not reflect every

feature or option of your particular model.

J-Bar, Pry Bar or Dolly Only (No Fork Lift)

• Caution! Do not push or pull on glass while

moving case into position!

• With several people in position, carefully

slide frame support rail to edge of skid.

• Slide case off skid and lower frame

support to floor.

• Once the frame support rail rests on the

floor, have several people supporting

front of case while skid is slid out from

under case.

• After case is off skid, several people

may be required to slide into position.

• Or, depending upon case weight, use

J-Bar to incrementally lift and rotate

case into desired position.

• Note: Illustrations shown may not

exactly reflect every feature or option of

your particular case.

Illustration Shown May Not

Reflect Every Feature Or Option

of Your Particular Case.
