CASE START-UP / THERMOMETER FUNCTION & LOCATION

1. Case Start-Up

• Case will energize when properly field-wired.

• Refrigeration system will supply cold air to rear

drawers, rear door compartment and front grab-n

-go section upon being energized.

• Front refrigerated section shown below. Light

switch (if any) will turn on light at front of case.

• When properly field-wired, coil fans should turn

on. From inside of the case, check for discharge

air from the air diffusing honeycomb to confirm

that fans are functioning properly. See next

page for honeycomb location.

Thermometer to

Refrigerated Front

Grab-N-Go Section

• When case is in start-up mode (or has been idle

for a long period of time), unit requires 75

minutes of run time to pull-down temperature.

2. Thermometer Function & Placement

• A. Thermometers may provides temperature to

separate areas in the case.

• B. Thermometers reflect warmest air

temperature in merchandiser. They do not

provide actual food temperature.

• C. Use probe thermometers to determine

actual product temperatures.
