Fusion® User Manual 20

Atmosphere Cleaning and Maintenance

Annual Maintenance

Order lter by calling Watts at 1-800-224-1299

Item Needed: # 7100110, 7100454

Includes:

• (1) Sediment Filter • (1) Carbon Block Filter

• (1) Final In-Line Filter

Sanitizing of unit is recommended.

Step A-Perform steps A through E in the Six Month System Maintenance.

If not sanitizing the system skip to step H.

Step B-Remove the RO membrane from its housing and rest in a clean sanitary place. (refer to “Membrane Replacement” for

direction on removing the membrane). Replace cap onto empty membrane housing and re-connect green tubing.

Step C-Leaving the lter out, replace Stage 1 and 2 empty lter housings (hand tight) onto unit. Measure & pour either 1/2 cup of

hydrogen peroxide or common household bleach into the 1st lter housing (Stage 1) and hand tighten onto unit.

NOTICE: Over-tightening components can damage the system causing water damage and/or system failure.

Step D-With the RO faucet in the closed position turn on the incoming water supply to the system by turning the Adapt-A-

Valve

counterclockwise. Wait 1 minute for the unit to pressurize. Turn on the RO faucet, and let the water run for 30 seconds.

Turn off the RO faucet, and let the unit rest for 2 minutes. Finally, open the R0 faucet, and let the water run for 5 more minutes.

Step E-Turn of the incoming water supply to the system by turning the Adapt-A-Valve

clockwise until it stops. Keep the RO

faucet open until the storage tank is completely drained.

Step F-Open the membrane housing and re-install the RO membrane while making sure not to kind the O-rings. (Refer to

“Membrane Replacement” section on Page 9 for directions on the installing the membrane). Tighten the cap back on the

housing and reconnect green turning.

Step G-Remove lter housing Stage 1 and 2 and empty of water.

NOTICE: Before re-installing the lter bowls back on to the system, check O-rings to make sure they are still in place and

lubricate with water soluble lubricant. Do not over-tighten lter housing, over-tightening may damage O-ring(s), cause

water leaks, or affect system performance.

Step H-Insert the new Sediment Filter (cloth like appearance) into the 1st lter housing which is the one on the water inlet side

(green tubing from the Adapt-A-Valve

) of the RO system and re-install housing.

Step I-Insert the new Carbon Block lter (white End Caps) into the 2nd housing and re-install housing.
