7
for other cutting devices and apply the specic
guard for the saw blade.
WARNING! This guard must not be used
for other cutting devices.
c) Disassembly
– Insert the supplied wrench (5) in the specic
hole, then turn the blade (3) by hand and push
the wrench (5) until it enters the hole of the an-
gle transmission (2), blocking rotation.
– Unscrew the nut (7) clockwise and remove
the cup (6).
– Pull out the outer ring-nut (4), then remove the
blade (3) and the inner ring-nut.
2. PREPARING TO WORK
2.1 CHECKING THE MACHINE
Before starting work please:
– check that all the screws on the machine and
the cutting device are tightly fastened;
– check that the cutting device is undamaged
and that the 3 or 4-point metal blades (if tted)
are properly sharpened;
– check that the air lter is clean;
– check that the guards are suited to the cutting
device being used, properly fastened and ef-
cient;
– check the handgrips are well fastened.
2.2 PREPARING THE FUEL MIXTURE
This machine is tted with a two-stroke engine
which requires a mixture of petrol and lubricat-
ing oil.
IMPORTANT Using petrol alone will damage the
engine and is cause for invalidation of the war-
ranty.
IMPORTANT Use only quality fuels and oils to
maintain high performance and guarantee the du-
ration of the mechanical parts over time.
2.2.1 Petrol characteristics
Only use unleaded petrol with a fuel grade of at
least 90 ON.
IMPORTANT Unleaded petrol tends to create de-
posits in the container if preserved for more than 2
months Always use fresh petrol!
2.2.2 Oil characteristics
Only use top quality synthetic oil specically for
two-stroke engines.
Your Dealer can provide you with oils which have
been specically developed for this type of en-
gine, and which are capable of guaranteeing a
high level of protection.
The use of these oils makes it possible to pre-
pare a 2% mixture, consisting in 1 part oil to 50
parts petrol.
2.2.3 Preparation and preservation
of the fuel mixture
DANGER! Petrol and the fuel mixture are
highly inflammable!
– Keep the petrol and fuel mixture in homolo-
gated fuel containers, in a safe place, away
from any flames or heat sources.
– Never leave the containers within the reach
of children.
– Never smoke whilst preparing the mixture
and avoid inhaling the petrol fumes.
To prepare the fuel mixture:
– Place about half the amount of petrol in a ho-
mologated tank.
– Add all the oil, according to the chart.
– Add the rest of the petrol.
– Close the top and shake well.
IMPORTANT The fuel mixture tends to age. Do
not prepare excessive amounts of the fuel mixture
to avoid the formation of deposits.
IMPORTANT Keep the petrol and fuel mixture
containers separate and easily identifiable to
avoid the mistake of using one in place of the
other.
IMPORTANT Periodically clean the petrol and
fuel mixture containers to remove any eventual
deposits.
2.3 REFUELLING
DANGER! Never smoke whilst refuelling
and avoid inhaling the petrol fumes.
WARNING! Carefully open the tank top
as pressure could have formed inside.
Before refuelling:
– Shake the fuel mixture container well.
– Place the machine on a at stable surface,
with the fuel tank cap facing upwards.
