ENGLISH
EN
Original instructions for use
1 GENERAL
This symbol indicates CAUTION. Seri-
ous personal injury and/or damage to
property may result if the instructions
are not followed carefully.
You must read these instructions for
use and the machine’s safety instruc-
tions and instructions for use carefully.
1.1 References
The figures in these instructions for use are num-
bered 1, 2, 3, etc.
Components shown in the figures are marked A, B,
C, etc.
A reference to component C in figure 2 is written
“2:C”.
2 SAFETY INSTRUCTIONS
• Please read
through these instructions carefully.
Learn all the controls and the correct use of the
unit.
• Carefully read and understand the safety in-
structions supplied in a separate book together
with the machine.
3 DESCRIPTION
3.1 General
The quick connections are intended for use on
GGP’s machines, Stiga Park, Castelgarden XK
and Mountfield 4140 and 4155, 2WD and 4WD.
The quick connections can be separated, which
makes it very easy to shift between the different
implements.
The quick connections allow the deck to be moved
easily between the two positions:
• Normal position with fully tensioned belt.
• 4 cm behind the normal position with slackened
belt so that the deck gets closer to the base ma-
chine.
As the belt idler is released from the belt, the quick
connections simplify belt and deck replacement,
and also make shifting to the washing position and
service positions easier.
3.2 Delivery
The delivery consists of the following compo-
nents. The figures only display the right-hand side,
but the numbers below refer to both sides.
4 ASSEMBLY
Install the quick connections according to the in-
structions below.
1. Only applies to 2WD machines; Lubricate the
shaft ends of the machine and the quick connec-
tion’s bearing surface with oil before installa-
tion.
2. Install the deck sections of the quick connec-
tions to the deck arms according to fig. 2.
3. Install the shaft sections of the quick connec-
tions to the machine according to fig. 1 and fig.
2.
4. Only applies to 2WD machines; Bend out the
cotter pin’s (3:F) leg along the periphery of the
shaft in order to secure it in the shaft.
5. Set the mountings to their rear positions and
hook the deck arms into position. See fig. 5.
6. If the belt is mounted, the belt tension can be re-
leased by unhooking the belt idler from the belt.
See fig. 7 and 8.
7. Set the quick connections to their front posi-
tions and install the locking pins (6:A).
8. Only applies to 4WD machines; Lubricate the
lubricating cup for the quick connection using a
grease gun until grease penetrates alongside the
shaft. See fig 9.
Position 2WD, fig 1, 2, 3 4WD, fig 1, 2, 4
A 2 locking pins 2 locking pins
B Quick connection
deck section, right
and left
Quick connection
deck section, right
and left
C Quick connection
shaft section, right
and left
Quick connection
shaft section, right
and left
D 2 screws 2 screws
E 2 nuts 2 nuts
F 2 cotter pins 2 locking rings
G 4 washers 4 washers
