EN
This User Manual has been translated using machine translation. We have made every effort to
ensure the translation is accurate, but please note that automated translations are not perfect
and are not meant to replace human translators. The official version of the User Manual is in
English. Any differences between the translated version and the original English are not legally
binding. If you have any questions about the accuracy of the translation, please refer to the English
version, which is the official reference. More language versions are available upon request via
info@expondo.com
Technical data
Parameter description Parameter value
Product name
Laminar flow cabinet (vertical type)
Model
SBS-LFC-100
SBS-LFC-200
Rated voltage [V~] / frequency [Hz]
230 / 50
Rated power [W]
240
440
Max power of socket
800
800
UV lamp power [W]
20
30
LED lamp power [W]
16 (x2)
24 (x2)
Protection class
I
Dimensions [width x depth x height; mm]
1060 x 795 x 1830
1460 x 792 x 1850
Weight [kg]
142.5
171
Inside chamber dimensions [mm]
920 x 690 x 650
1320 x 690 x 650
Duty cycle
S1
Filter type
HEPA 99.999% efficiency at 0.3 µm
Emitted noise [dB(A)]
60
Max load capacity [kg]
50
Air velocity measurement [m/s]
0.2~0.6
Remote controller battery type
CR2025
This appliance is a type of workstation designed to create a clean, particle-free working environment by directing
filtered air vertically over the workspace. It operates by drawing air from the room, which is then filtered through
a High-Efficiency Particulate Air (HEPA) filter before being directed downwards in a laminar (unidirectional) flow.
It is crucial in environments requiring high standards of cleanliness, such as in life sciences, certain manufacturing
processes etc.
This product is outside the scope of REGULATION (EU) 2017/745 for medical devices. It has not been designed
as a medical device.
A. Room air
B. Cleaned air
