Bypass
With the Bypass Pads button to the right of the trigger pads, you can bypass the
entire pads section. This deactivates any functionality you assigned to the trigger
pads.
Assigning Trigger Notes to Pads
You can assign a MIDI note to a pad and trigger the pad by playing this note.
To dene the trigger note, do one of the following:
● Right-click a pad, open the Assign Trigger Note submenu, and from the further
submenus, select the octave and note that you want to assign.
●
Open the context menu for a pad, select Learn Trigger Note, and play the note on your
MIDI keyboard or click a key on the internal keyboard.
The name of the assigned trigger note is displayed in the top left corner of the pad.
On the internal keyboard, keys that serve as trigger notes are shown in blue. These keys do not
play sounds, but trigger the corresponding pads instead.
●
To remove a trigger note from a pad, right-click the pad and select Forget Trigger Note.
Assigning Chords or Notes to Trigger Pads
PROCEDURE
1. Right-click a pad and select Snapshot Chord.
The pad starts blinking.
2. Do one of the following:
● Play a chord or a single note and then click the pad that is blinking to assign the
chord or note to the pad.
● Drag a chord event from the chord track of your Steinberg DAW onto a trigger pad.
This transfers the corresponding MIDI notes to the pad.
If you drag a chord event onto the internal keyboard rst, the corresponding chord
is played back. This is useful to verify whether you selected the correct chord.
If you dene a chord that contains a key switch, you can trigger the chord with a specic
instrument expression.
If you add keys to a chord that also work as trigger notes, they trigger the underlying MIDI
note instead of the trigger note.
RESULT
Triggering the pad now plays the chord or note.
Default Trigger Note Settings
Assigned trigger notes are saved with each program to allow for maximum exibility. However,
you can save a xed set of default trigger notes to reect an existing hardware setup, for
example.
●
To specify a default set of trigger notes, set up the trigger notes for all pads, right-click a
pad, and select Save Trigger Notes as Default.
●
To activate the default trigger note settings, right-click a pad and select Use Default
Trigger Notes.
Now, changing programs or multi-programs does not change the trigger notes anymore.
Global Functions and Settings
Trigger Pads
21
HALion Sonic 3.4.0
