GX2200

9

16

Key

 Pressthe

9

16

keybrieytorecallChannel16fromanychannellocation.

Pressandholdthe

9

16

 key to recall Channel 9. Pressing the

9

16

 key

againrevertstothepreviousselectedworkingchannel.

DISTRESS

Key

 UsedtosendaDSCdistresscall.Tosendthedistresscallreferto

section“9.3.1 Transmitting a DSC Distress Call”.

7.2 REAR PANEL

Never remove this rubber cap.

When this rubber cap is removed,

the water resistance performance is

lost.

ANTJack

(

AntennaJack

)

 Connectsanantennatothetransceiver.UseamarineVHFantennawith

animpedanceof50ohms.

Note:OntheGX2200theantennaconnectionisusedtoreceivemarine

andAISreceiver.

GND Terminal

(

Ground Terminal

)

 Connects the GX2200 to a good ground, for safe and optimum perfor-

mance.

 UsethescrewsuppliedwiththeGX2200only.

ExternalSpeakerConnectionCable

(

White & Shield

)

 ConnectstheGX2200toanexternalspeaker.Seesection“3 OPTIONAL

ACCESSORIES”foralistofoptionalSTANDARDHORIZONSpeakers.
