7 CONTROLS AND INDICATORS

NOTE

Thissectiondefineseachcontrolofthetransceiver.Seeillustra-

tionatthenextpageforlocationofcontrols.Fordetailedoperating

instructionsrefertochapter8ofthismanual.

7.1 FRONT PANEL

CH Knob(ChannelSelection)

 Rotaryknobisusedtoselectchannelsandtochoosemenuitems(such

astheDSCmenu,GeneralSetupandDSCSetupmenu).The

/

keysonthemicrophonecanalsobeusedtoselectchannelsandmenu

items.

SeConDary uSe



 PressthisknobtoenteraselectioninthesetupmenuorDSCmenu.



While holding the

soft keyandturningthisknob, youcan

conrmmemorychannelsthathavebeenprogrammedforscanning.



When in the PAor Fog mode, turning this knob changes the output

volumeoftheconnectedhornspeaker.

PWR/VOLKnob

(

PowerSwitch/VolumeControl

)

 Turnsthetransceiveronandoffaswellasadjuststhespeakervolume.

 Toturnthetransceiveron,pressandholdthisknobuntiltheradioturns

on.

 Whenthepoweristurnedon,thetransceiverissettothelastselected

channel.Clockwiserotationofthisknobincreasestheinternaland

speakermicrophonevolume.

 Toturnthetransceiveroff,pressandholdthisknobuntiltheradioturns

off.
