Page28

GX2200

Wall

Gasket

MountingBracket

RoutingCable

Cap

Nut

ExternalSpeakerConnections

FerriteCore

NOTE

Caution!: Before cutting the cable, it must be disconnected from the rear

panel of the transceiver.

Theroutingcablecanbecutandspliced,howevercareneedstobe

takenwhenreconnectingthewirestoensurewaterintegrity.

Aftercuttingyouwillnoticetherearethefollowingwires:

Yellow,White,Brown,Gray,Blue,Green,Red/White



,Shield





Thered/whiteandshieldwiresarewrappedinfoil.Removethefoil,

andseparatethered/whiteandshieldwires.

WARNING

ItisnotrecommendedtoplugorunplugtheCMP30

(

RAM3

)

Remote

StationMicrophoneintotheroutingcablewhiletheradioison.
