HX850SPage 18
5 CONTROLS AND SWITCHES
NOTE
This section defines each control of the transceiver. For detailed operating
instructions, refer to section “6 BASIC OPERATION”. Refer to illustrations
for the location of the following controls, switches, and connections.
c
ANT Jack
(
Top Panel
)
The supplied CAT460 flexible antenna is attached here.
d
MIC/SP Jack
(
Top Panel
)
The jack accepts the optional MH-73A4B Speaker/Microphone, MH-57A4B
Mini Speaker/Microphone, VC-24 VOX Headset, or VC-27 Earpiece/Mi-
crophone. When this jack is used, the internal speaker and microphone
are disabled.
e
PTT
(
Push-To-Talk
)
Switch
(
Left side
)
When pushed activates the transmitter.
dc
f
g
h
i
j
k
e
l k
NOTE
When transmitting, position
your mouth about 1/2 to 1
inch (1.2 ~ 2.5 cm) away
from the small mic hole.
Speak slowly and clearly
into the microphone.
