Page 16
8. BASIC OPERATION
8.1 PROHIBITED COMMUNICATIONS
The FCC prohibits the following communications:
False distress or emergency messages.
Messages to “any boat” except in emergencies and radio tests.
Messages to or from a vessel on land.
Transmission while on land.
Obscene, indecent, or profane language
(
potential ne of $10,000
)
.
8.2 INITIAL SETUP
1. To install the antenna onto the transceiver; hold the bottom end of the
antenna, then screw it onto the mating connector on the transceiver until
it is snug. Do not over-tighten.
8.3 RECEPTION
1. Press and hold the POWER key for one second to turn the radio “ON”.
2. Press and hold the [SQL] switch until the
“
” indicator appears on the display. This
is the “squelch o” state.
2. Press the [VOL-] or [VOL+] key until noise
or audio from the speaker is heard at a
comfortable level.
3. Press the [SQL] switch to resume normal (quiet) monitoring.
5. Press the [p] or [q] key to select the desired channel. Refer to the channel
chart on page 46 for available channels.
6. When a signal is received, adjust the volume to the desired listening level.
The “ ” indicator on the LCD is displayed indicating that the channel
is being used or the radio is not squelched.
8.4 TRANSMISSION
1. Setup the transceiver as described in the “8.3 RECEPTION” discussion
above.
2. Before transmitting, monitor the channel and make sure it is clear.
THIS IS AN FCC REQUIREMENT!
3. Press the PTT (Push-To-Talk) switch to
transmit. During transmission, the “
”
indicator will appear on the display.
4. Position the microphone about 1/2 to 1 inch (1.2 ~ 2.5 cm) away from your
mouth. Speak slowly and clearly into the microphone.
5. When the transmission is nished, release the PTT switch.
