page 18 Owner’s Manual HX260S
5.3 USING BATTERY TRAY
1. Push the lock of the battery tray, and
open the lid.
2. Install the AA battery cell.
(We recommend you use alkaline
batteries.)
3. Confirm the polarity of the batteries.
4. Close the lid.
5. Attach the battery tray to transceiver,
and turn the lock screw clockwise 1/4
turn.
CAUTION
It is not recommended to use Ni-Cd batteries or other rechagable batteries.
5.3 OPERATING CWC260 BATTERY CHARGER
1. Turn the transceiver off.
2. Plug the DC plug of CWC260 into the
battery.
3. Plug the wall charger into a 120 VAC
wall outlet.
4. The indicator lights, and charging begins.
5. Remove the DC plug from the battery
when charging time has passed.
Figure 9. Installing the battery pack
Figure 8. Removing the battery case lid
L
O
C
K
O
P
E
N
Figure 11.
Plugging the DC plug
Figure 10. Confirm the polarity
