HX260S Owner’s Manual page 17
5 BATTERY
5.1 BATTERY CHARGING
To check the charge status, install the battery and press the PTT switch
while observing the BATT indicator. (see page 9)
The CWC260 battery charger supplied with the transceiver recharges a
completely discharged CNB260 battery pack in about 15 hours.
Battery pack should not be charged with the supplied battery charge
system for longer than 16 hours.
See figure 11 for diagram of connecting the charger to the battery.
5.2 BATTERY PACK REMOVAL/INSTALLATION
1. Turn the transceiver off.
2. Turn the battery lock screw counter-
clockwise 1/4 turn.
3. Pull the battery pack to upward and
remove the battery pack.
4. Attach the battery pack to transceiver.
5. Turn the battery lock screw clockwise
1/4 turn.
Figure 5. Turning the battery lock
L
O
C
K
O
P
E
N
Figure 6. Removing the battery pack
Figure 7. Attaching the battery pack
