Page 24 GPS Chart 160/170C
Shows the graph of the Water Temperature received from the NMEA Port. Pressing
'ZOOM IN'/'ZOOM OUT' changes the time scale.
Figure 3.2.7.5 - Temp Graph Page
NOTE
Changing time scale will delete all points on the graph.
3.2.7.6 SOG Trend Page
'MENU' + "NMEA DISPLAY" + 'ENTER' + "SOG TREND" + 'ENTER'
or
press any soft key + 'SOG' (if it is present)
Shows the graph of the vessel Speed received from the NMEA Port. Pressing 'ZOOM
IN'/'ZOOM OUT' changes the time scale.
Figure 3.2.7.6 - SOG Graph Page
NOTE
Changing time scale will delete all points on the graph.
