74 75
Rev. 04.04.2022 Rev. 04.04.2022
9.
10.
Grounding: At the back of each welder there is
a screw and a label to provide the necessary
grounding. Before operating the unit it is
necessary to ground the shell of the welding
apparatus by means of a cable with not less than
6 mm diameter, in order to prevent potential
problems caused by electricity leakages.
Additional power supply connection to the plasma torch cable.
11.
12.
POST TIME = gas ow variable at second intervals. This regulation is
important for the cooling of the cut melted metal after the cutting
process and to protect against oxidation.
ROCKER SWITCH = If the cutter (the workpiece) is not in deter-
mined, automatically set position, button on the cutting torch should
be pressed in order to begin cutting. In order to nish cutting, button
on the torch should be released. Such cutting type is useful for short
seam. If the workpiece is in determined, automatically set position,
button on the torch should be pressed once in order to start the
plasma arc. Such action allows for uninterrupted cutting. Press the
button on the torch again to stop cutting. This cutting type is useful
for cutting longer seams.
SWITCH
DEEN
13.
14.
4T/2T selection button
POST FLOW = setting the time of the air ow after the cutting.
15.
16.
TEST GAS = protection
U.V LED = Under Voltage LED. This LED control light will turn on
when the voltage drops under 330 V.
17.
O.V LED = Over Voltage LED. This LED control light will turn on
when the voltage rises above 420V.
18.
GASSHT = this control light will turn on when air ow is not availab-
le or is insufcient.
19.
PHASEN STROMVERLUST = this control light will turn on when
device is connected to 1 or 2 phases (instead of 3) – device stops
working.
DE
20
CNC connection socket.
EN
