12
EN
THE DEVICE CAN STILL BE UNDER VOLTAGE UPON FEEDER DISCONNECTION
• Voltage in the input capacitor must be checked upon turning off the device and disconnecting it from
the power source. One must make sure that the voltage value is equal to zero. Otherwise, the device
elements must not be touched.
1.5 GASES AND FUMES
PLEASE NOTE! GAS MAY BE LETHAL OR DANGEROUS TO HUMAN HEALTH!
• Attention must be paid to proper ventilation in the work area, concurrently avoiding gas inhalation.
• Chemical substances (lubricants, solvents) must be removed from the surfaces of welded details as they
burn and emit toxic smokes under the inuence of temperature.
• Welding galvanised details is permitted only when efcient ventilation is provided with ltration and
access to fresh air. Zinc fumes are highly toxic, an intoxication symptom is so-called metal fever.
2. TECHNICAL SPECIFICATIONS
Product name Welding machine
Model S-MMA 120.IGBT S-MMA 180.IGBT S-MMA 200.IGBT S-MMA 250.IGBT
Voltage / frequency 230V~ 50 Hz
No load voltage 56 V
MMA welding current 20-120 A 20-180 A 20-200 A 20-250 A
Duty cycle 60 %
Welding current [A] at
duty cycle 100%
93 A 139 A 155 A 193 A
IP protection class IP21
3. OPERATION
3.1 GENERAL NOTES
• The device must be used according to its purpose, with observance of OHS regulations and restrictions
resulting from data included in the rating plate (IP level, operation cycle, supply voltage, etc.).
• The machine must not be opened as it will cause warranty loss and, in addition, exploding, unshielded
elements can cause serious injuries.
• The producer does not bear any responsibility for technical changes in the device or material losses
caused by the introduction of the said changes.
• In case of incorrect device operation, contact the service centre.
• Louvers must not be shielded - the welder must be positioned at 30 cm distance from objects
surrounding it.
• The welder must not be kept under your arm or near to your body.
• The machine must not be installed in rooms with aggressive environments, high dustiness and near
devices with high electromagnetic eld emission.
3.2 DEVICE STORAGE
• The machine must be protected against water and moisture.
• The welder must not be positioned on heated surfaces.
• The device must be stored in a dry and clean room.
