1 Thread holes (M10), suitable for connecting elements

2 Safety cable eyelet

3 Locking screws for the bracket

4 Bracket for suspension or set-up

5 [DMX Out] | DMX output, designed as XLR panel socket, 3-pin

6 [DMX In] | DMX input, designed as XLR panel plug, 3-pin

7 Fuse holder

8 [POWER IN] | Lockable input socket (Power Twist) for the power supply of the device

9 [POWER OUT] | Lockable output socket (Power Twist) for powering further devices

10 Display

[Mode] | Activates the main menu and toggles between menu items. Closes an open submenu.

[Setup] | Selects an option of the respective operating mode, conrms the set value.

[Up] | Increases the displayed value by one.

[Down] | Decreases the displayed value by one.

Connections and controls

LED Matrix Blinder 5×5 MKII
