Each device must be assigned a DMX address if it is operated via a DMX controller. The device
will only react to control signals that are received on the set DMX address. To combine mul‐
tiple devices into a group, it is possible to assign the same DMX address to the relevant
devices.
In addition to the set DMX address, a device always occupies the number of DMX
channels that are set as DMX mode on the device. Other devices that will be con‐
trolled individually must always be assigned the next free DMX address according to
the channel assignment of other devices. Partial overlaps of channels can cause unin‐
tended eects.
Example:
If the rst device is set to the 2 CH DMX mode with the DMX address 1, the next device
must be set to DMX address 3 or higher.
The rule is: DMX address of additional device = DMX address of rst device + DMX
mode
1. Open the main menu.
2.
Navigate to ‘DMX Settings è DMX Address’.
3. Use [UP] and [DOWN] to select an address between 1 and 512/511/509/507.
4. Conrm your selection with [ENTER].
ð
The desired address is saved.
5. To exit the menu, press [MENU] or wait 30 seconds.
Setting the DMX address
Operating
DuoBlind 200 WW
23
