7.3 Sound control
1. Press [MENU] repeatedly until the display shows ‘Sou’ and conrm with
[ENTER].
2. Press [UP] or [DOWN] to select one of the sound-controlled programmes
‘So01’ … ‘So14’ .
3. Conrm the selection with [ENTER].
4. Use the [MIN/MAX] control to set the sensitivity of the built-in microphone.
5. To return to the main menu without making changes, press [MENU].
7.4 DMX operating mode
This setting is only relevant if the device is controlled via a DMX controller.
1. Press [MENU] repeatedly until the display shows ‘dMX’ and conrm with
[ENTER].
ð
The display shows ‘d 1’ .
2. Press [ENTER] again to open the settings menu for DMX mode.
3. Press [UP] or [DOWN] to select the required DMX mode and conrm with
[ENTER].
The following DMX modes are available:
Menu level 2 Description
‘02Ch’ 2-channel mode
‘05Ch’ 5-channel mode
‘08Ch’ 8-channel mode
‘10Ch’ 10-channel mode
5. After conrming DMX mode, press [UP] or [DOWN] to select a value between 1
and 512 for the required DMX address (display shows ‘d 1’ … ‘d512’ ) and con‐
rm your selection with [ENTER].
Make sure that this number matches the conguration of your DMX controller.
The following table shows the respective highest possible DMX address for the
various DMX modes.
Mode Highest possible DMX address
2-channel mode 511
5-channel mode 508
8-channel mode 505
10-channel mode 503
6. To return to the main menu without making changes, press [MENU].
Setting the DMX mode
Setting the DMX address
Operating
16
All FX Bar
LED Eect
