Basics 13

Stanford Research Systems DC215 Voltage/Current Source

Shifted Key Functions

The numeric keys have secondary functions that are either menus or direct actions.

These are accessed by first pressing [SHIFT] to enter the shift mode and then pressing

the desired key. The shift indicator is illuminated when in the shift mode. See the topics

listed for details.

▪ [SHIFT] [±] (Store): Store instrument settings 1 – 9. See Store (page 58) for

details.

▪ [SHIFT] [7] (Recall): Recall instrument settings 1 – 9, or the default setting 0.

See Recall (page 58) for details.

▪ [SHIFT] [8] (Sense): Set voltage sense to 2 or 4 wire. See Sense (page 32) for

details.

▪ [SHIFT] [9] (Guard): Set the Guard on or off. See Guard (page 32) for details.

▪ [SHIFT] [CLR] (Local): Set the remote interface to local. See Remote

Programming (page 111) for details.

▪ [SHIFT] [.] (Seq): Enter the Sequencer menu. See Sequencer (page 37) for

details.

▪ [SHIFT] [4] (Meas): Enter the Measurements menu. See Measurements (page

33) for details.

▪ [SHIFT] [5] (Comm): Enter the Communication menu. See Communication (page

73) for details.

▪ [SHIFT] [6] (Log): Enter the Logging menu. See Logging (page 52) for details.

▪ [SHIFT] [0] (BW): Set the Bandwidth to Hi or Lo. See Bandwidth (page 31) for

details.

▪ [SHIFT] [1] (Rel): Toggle the voltage and current monitor Rel setting. See Rel

(page 34) for details.

▪ [SHIFT] [2] (Mon V/I): Toggle the displayed Monitor value. See Measurements

(page 33) for details.

▪ [SHIFT] [3] (Util): Enter the Utility menu. See Utilities (page 63) for details.

▪ [SHIFT] [PAUSE]: Pauses/resumes a ramp. See Ramping (page 25) for details.

▪ [SHIFT] [STEP]: Jumps to the final point of a ramp. See Ramping (page 25) for

details.

▪ [SHIFT] [CLR]: Cancels a ramp and reverts to the previous source value. See

Ramping (page 25) for details.

▪ [SHIFT] [Enter]: Loads the Real Time value to the source value & ends a ramp.

See Ramping (page 25) for details.
