Manual Conventions and Organization ii

Stanford Research Systems DC215 Voltage/Current Source

Quick Start Guide

What’s Needed

Equipment required to briefly evaluate the DC215.

▪ Precision DMM with at least 5 digits resolution

▪ 2 banana plug test leads

▪ 2 banana to clip leads

▪ 1 kΩ resistor

Refer to Chapter 2 (page 9) for a detailed description of the DC215 front panel controls

and rear panel.

Note: [Enter] refers to either the [V/A] or [mV/mA] keys.

Example 1: Turning on the Instrument

This section describes the initial steps for first operating the DC215. Pay special

attention to the AC line selector setting.

Power Entry Module

Verify that the rear panel power entry module is properly configured for the line

voltage in your region. Applying power with the incorrect line voltage setting may

result in significant damage to the DC215. See Fuse Installation and Line Select (page

171) for details.

1) Plug the AC line cord into the rear panel power entry module and then into a

grounded wall outlet.

2) Press the Power Button (lower right side of the front panel) while holding the [CLR]

key down to reset the instrument to its factory default state.

3) Power cycle the DC215 (off-on).

4) Observe the sign on messages and Self Test.

a. The model (dc215) and firmware version (x.xx) are displayed

b. Next the serial number is displayed

c. Finally the Self Test message is shown, followed by either “test PASS” or

“test FAIL”. See Self Tests (page 169) in case the Self Tests fail.

5) At this point the unit is in the default configuration, with the output off. Allow the

unit to warm up for a hour for full specified performance. Warm up is not

necessary to test basic functionality.
