Specifications xiii
Stanford Research Systems DC215 Voltage/Current Source
Ramping
The output can be set to ramp between output settings
Ramp Time: 0 - 3600.0 s with 0.1 s resolution
Reactive Loads
Reactive (not purely resistive) loads may increase the rise, settling and response times due to an over or
under damped response. Large reactive loads may slow these times significantly due to the limiter
behavior.
Maximum reactive loads
Output
HiBW
LoBW
Capacitive Load (Voltage Out, Voltage Limit)
tbd
≥100 μF
Inductive Load (Current Out, Current Limit)
tbd
≥1 mH
Limiting
Independent positive and negative limits. Limits are not active to 10 & 100 mV ranges.
Limit
Limit Magnitude
Limit Resolution
Current Limit
(Active for 1, 10 & 30 V ranges
1 mA to 240 mA
1 mA
Voltage Limit
(Active for 1, 10, 100, 200 mA ranges
0.1 V to 32 V
0.1 V
Output Sequences
A variable length output sequence can be created from the front panel, downloaded over the remote
interfaces or loaded from a USB drive. Sequences are for a single output type (voltage or current) and
use the selected ramp time.
Number of steps 2 – 10000
Step Trigger Source Manual, Timed (0.1 - 3600.0 s with 0.1 s resolution), Command,
External Step Trigger or Measurement End
