FLW213R_SVG
"d 1"
Control Software
Version Number Test
"d 3"
Drive Board #1
Software Version Test
"d 7"
Water Level
Trim Test
"d 8"
Service Door Switch
Input Test
"d 9"
Coin Vault Switch
Input Test
"diAg"
Diagnostic Tests
"d 10"
Coin Drop #1
Input Test
"d 11"
Coin Drop #2
Input Test
"d 12"
Vend Connection Header
Present Input Test
"d 13"
Start Pulse
Input Test
"d 15"
Door Switch
Input Test
"d 17"
Show Fill
Time Test
"d 16"
Door Lock Switch
Input Test
"d 18"
Show Drain
Time Test
"d 22"
Out of Balance Switch
Input Test
"d 23"
External Output Test
"d 24"
Water Purge Test
"d 26"
Water Level Test
"d 27"
DC Bus Voltage Test
"d 29"
Machine Configuration #1
Display Test
"d 28"
AC Mains Voltage Test
"d 25"
Water Leak
Detection Test
"d 30"
Machine Configuration #2
Display Test
"d 31"
Machine Configuration #3
Display Test
"d 32"
Machine Configuration #4
Display Test
"d 33"
Machine Configuration #5
Display Test
"d 47"
Card Reader
Communication Test
Figure 16
Testing Machine and Electronic Control Functions
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
98 Part No. 807870ENR4
