the number of minutes to be added to steps that have Rinse 1
selected as their status.
7. Press the DELICATE (∧) or the HOT (∨) keypad to increase
or decrease the current number of minutes
8. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
How to Enter Cycle Programming
CyCLE-
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2.
Press the DELICATE (∧) or the HOT (∨) keypad until Prog
appears in the display. Press the START (enter) keypad, and
AtS 1 will appear in the display.
3. Press the DELICATE (∧) or the HOT (∨) keypad to scroll
through the programmable options until CyCLE- appears in
the display. Press the START (enter) keypad and CyCLE1
will appear in the display.
NOTE: The LED light next to the select cycle keypad
will be lit to indicate which cycle is being program-
med.
4. Press the DELICATE (∧) or the HOT (∨) keypad to scroll
through the cycles to program.
5. Press the START (enter) keypad when the desired cycle ap-
pears in the display. PCyCtd will appear in the display if ena-
bled. Otherwise the first cycle step will appear. Refer to Table
12 for keypad navigation.
6. For each cycle, the Programmable Cycle Time Display can be
programmed, if enabled in Global Programming Parameters
(refer to Programmable Cycle Time Display PCyCtd ). Press
the START (enter) keypad to program the displayed time.
7. Press the DELICATE (∧) or the HOT (∨) keypad until the de-
sired value is on the display. Values range from 0 - 65,535. A
value of 0 will disable Programmable Cycle Time for the se-
lected cycle. This allows for some cycles to use a Programma-
ble Cycle Time while others use the time calculated from the
enabled steps.
8. Press the START (enter) keypad. The new value is saved and
01 XXXX appears in the dispay. The first two digits represent
the Cycle Step number and will flash. XXXX will show the
step type. The machine is able to have up to 50 custom steps
programmed for each cycle. Within each step there are several
programmable options. Refer to the following sections for de-
tails about each step type and its options.
9.
After the last cycle step is stored, CyCEnd is displayed. If 50
steps are programmed CycEnd will not be displayed. To in-
sert a step at the end of the cycle, first go to this display and
then press the NORMAL key pad.
Functionality of Keypads in Cycle Programming
Keypad Level 3 Level 4 Level 5 Level 6
Start (Enter) Enters Level 4. If on Programmable Cy-
cle Time Display Param-
eter, key press saves cur-
rent value and goes back
to Level 3. Otherwise it
loads default parameter
values for the step if the
step type has changed,
saves the set step type
into the Programmable
Cycle, and enters Level
5.
Enters Level 6. Saves current parameter
value being programmed
into the Programmable
Cycle.
DELICATE (∧) Moves to the next pa-
rameter.
If on Programmable Cy-
cle Time Display Param-
eter, key press increases
parameter value, other-
wise moves to next Step
Type.
Increases the Step Pa-
rameter.
Increases parameter val-
ue.
Table 12 continues...
Programming Control
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
75 Part No. 807870ENR4
