Factory Test
To Enter Factory Test
1. Be certain control is in Ready Mode or Start Mode and access
panel or coin vault is open.
2. While pressing and holding the ULTRA modifier keypad with
one hand, press the HOT keypad with the other hand.
3. When the control enters Factory Test, it will display the first
test step, Machine Type.
4. The control will advance through the sequence of test steps
whenever START (enter) is pressed, with the exception of the
Keypad Test and Pressure Sensor Test. Refer to the table be-
low for all tests in the Factory Test.
To Exit Factory Test
To exit a test step, disconnect the machine from electrical power.
Factory Test Quick Reference Chart
Display Test Mode Comments
FL
Control Type FL is the control type.
XXX.XXX
Software Version Number
XXX is the control version number.
drAin or PUNP
Drain Type
The control will show drAin if it is con-
figured for a gravity drain. It will show
PUNP if it is configured as an electric
pump machine. The control will remain
in this mode until the Start keypad is
pressed.
HEAt
Heater Installed
The control will show HEAt if it is con-
figured for a Water Heater. The control
will skip this step if it is not configured
for a Water Heater. The control will re-
main in this mode until the Start keypad
is pressed.
tX
Control Level The control will display the control level
as Display 1.
PAdXX
Keypad Test
XX is the number of the keypad being
pressed. You need to press all keypads to
advance to the next step.
8.8.8.8.8.8
Display Test All LEDs and display segments will
light.
CXCX
Coin Drop Test
X is the number of coins entered. Coin
drop #1 is shown on the left of the dis-
play and coin drop #2 is shown on the
right of the display.
CArd
Card Reader Test
CArd is displayed when a card reader is
connected but not driving the display.
v oP or v CL
Coin Vault Test
v oP is displayed when coin vault
switch is open. v CL is displayed when
coin vault switch is closed.
Table 32 continues...
Testing Machine and Electronic Control Functions
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
106 Part No. 807870ENR4
