Configura-
tion Value
Life Test
Jumper
Present
Comm
Board "B"
Header
Present
Comm
Board "A"
Header
Present
Vend Con-
nection
Present
Coin Drop
#2 Present
Coin Drop
#1 Present
62 YES YES YES YES YES NO
63 YES YES YES YES YES YES
Table 30
Configuration 2 Display Test d 30
This option is not used on this model.
Configuration 3 Display Test d 31
This option is not used on this model.
Configuration 4 Display Test d 32
This option shows the user which dipswitches are set on the con-
trol.
To start test, control must be in the Testing Mode. Refer to How
to Enter Testing Feature at the beginning of this section.
To Enter, press the START (enter) keypad. The display will show
d XXX with XXX representing a configuration value as shown in
Table 31 .
If supply voltage is 100-127 Volt per phase, the voltage configu-
ration should be 120 Volt.
If supply voltage is 200-240 Volt per phase, the voltage configu-
ration should be 240 Volt.
To exit Machine Configuration 4 Display Test, press the WARM
(<) keypad. The control will return to the Testing Mode.
Each column in the table below contains a unique combination of
the words “ON” and “OFF” that indicates if that column’s dips-
witch is set on or off when the value is displayed.
Configuration
Value
Dipswitch 8
Pump (OFF)
Gravity Drain
(ON)
Dipswitch 7
Heater Disa-
bled (OFF)
Heater Ena-
bled (ON)
Dipswitch 3
Payment Sys-
tem Not
Present (OFF)
Payment Sys-
tem Present
(ON)
Dipswitch 2
Energy Cycle
Dipswitch 1
120 Volt Sup-
ply (OFF)
240 Volt Sup-
ply (ON)
0 OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF ON
2 OFF OFF OFF ON OFF
3 OFF OFF OFF ON ON
4 OFF OFF ON OFF OFF
5 OFF OFF ON OFF ON
6 OFF OFF ON ON OFF
7 OFF OFF ON ON ON
64 OFF ON OFF OFF OFF
65 OFF ON OFF OFF ON
Table 31 continues...
Testing Machine and Electronic Control Functions
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
104 Part No. 807870ENR4
