Notes

 The IP stream bandwidth for available input is

24G/12G by disabling/enabling the Clean

Switch regardless of whether the video data is

in a compressed or uncompressed format.

According to the priority, the bandwidth of the

input signal set in each “IP Input” is added. If

the total is within the bandwidth for available

input, the "IP Input" is judged to be valid (Valid),

and if it is outside the bandwidth, the "IP Input"

 Image Format: According to the

frame rate of the input IP

stream video data, select the

image format from the

following. The image format of

the frame rate set in “Frame

Rate” becomes enabled.

 59.94/29.97: 2160/

59.94P_12G, 2160/29.97P_6G,

1080/59.94P_3G, 1080/

59.94I_1.5G, 1080/

29.97PsF_1.5G, 720/

59.94P_1.5G

 50/25: 2160/50P_12G, 2160/

25P_6G, 1080/50P_3G, 1080/

50I_1.5G, 1080/25PsF_1.5G,

720/50P_1.5G

 24: 2160/24P_6G, 1080/

24PsF_1.5G

 23.98: 2160/23.98P_6G, 1080/

23.98PsF_1.5G

V Compression Select whether the input IP stream

vide

data is in uncompressed

(Uncompressed) format or in

compressed (JPEG XS) format.

 Uncompressed

 JPEG XS

A Interpolation If there is an excess or shortage in

audio data, s

elect whether to

complement (Interpolate) the data.

 Disable: Does not perform the data

interpolation.

 Enable: Performs the data

interpolation.

Audio CH Select the number of incoming

channe

ls f

or the audio data.

 2CH

 4CH

 8CH

 16CH

Note

The setting value must match the

number of audio channels set on the

transmitting device.

IP Input4 Displays valid (Valid)/invalid (Invalid) of

the IP Input4 input.

 Priority: Select the priority order of

the IP Input4 input.

 Priority1 - 4: Select the priority

order. “Priority1” is the first

priority.

 No Assign: Select when not

using IP Input4 input.

Submenu Setting

 Image Format: According to the

frame rate of the input IP

stream video data, select the

image format from the

following. The image format of

the frame rate set in “Frame

Rate” becomes enabled.

 59.94/29.97: 1080/59.94P_3G,

1080/59.94I_1.5G, 1080/

29.97PsF_1.5G, 720/

59.94P_1.5G

 50/25: 1080/50P_3G, 1080/

50I_1.5G, 1080/25PsF_1.5G,

720/

50P_1.5G

 24: 1080/24PsF_1.5G

 23.98: 1080/23.98PsF_1.5G

V Compression Select whether the input IP stream

video dat

a is in uncompressed

(Uncompressed) format or in

compressed (JPEG XS) format.

 Uncompressed

 JPEG XS

A Interpolation If there is an excess or shortage in

audio dat

a, select whether to

complement (Interpolate) the data.

 Disable: Does not perform the data

interpolation.

 Enable: Performs the data

interpolation.

Audio CH Select the number of incoming

hannels

for the audio data.

 2CH

 4CH

 8CH

 16CH

Note

The setting value must match the

number of audio channels set on the

transmitting device.

Copy From Copy other IP input configuration

preset data to the selected IP input

configuration preset. You can select

from “Preset 1” to “Preset 10”.

Cancel Restores the changed or confirmed

tings to the state before change.

Confirm Saves and applies the changed or

onf

irmed settings.

Submenu Setting
