Administrating the Camera
Setting the Action output — Action output Menu
54
• A maximum of 500 movie records can be saved to an
memory card. If the checkbox of Overwrite is not
selected when the number of records reaches 500, new
recordings cannot be made. If the checkbox of
Overwrite is selected when the number of records
reaches 500, the unit will begin to overwrite old
records in ascending chronological order.
• Overwrite is not available for a memory card of less
than 4 GB.
• When you record the H.246, set the video codec as
follows:
–Set the
Bit rate
below 2000 kbps.
–Set the
Frame rate
below 30 fps.
–Set the
I-picture interval
to 1 second.
• When you record the JPEG with image size 1280 ×
720 or above, set the video codec as follows:
– SNC-VB635/VB630/VM630/VM631/VM601/
VM632R/EB630/EB630B/EM630/EM631/
EM632R/XM637/XM636/XM632: Set the Image
quality below 2.
– SNC-VB600/VB600B/VM600/VM600B/
VM601B/VM602R/EB600/EB600B/EM600/
EM601/EM602R: Set the Image quality below 5.
–Set the
Frame rate
to 1 fps.
• When you record, set the
Image codec 2
and
codec 3
of the
Video codec
tab in the Video / Audio
menu to
Off
.
• When you set the image codec to VBR (CBR: Off) of
H.264 and record it, the recorded data may become
very large and the video/audio may be interrupted
depending on the setting for recording and scene. Be
sure to check the setting and environment of video
codec before use.
Common setting
Memory card
Display the available free space of external memory.
Overwrite
Select On to overwrite the file when there is insufficient
memory space.
When you select the checkbox, overwrite is enabled.
Old records will be overwritten in chronological order.
When you deselect the checkbox, overwrite is
prohibited, and no recording will be performed.
Note
Records are overwritten in chronological order,
regardless of whether they are movies or still images.
Edge Storage still image
Recording data
You can refer to still image files recorded in the memory
card. These files will be saved in a folder tree as follows.
/sdcard/EdgeStoragePicture/00000000-999999999/
00000000-99999999/
Path: Displays the path name of the recording still
image file.
When you select a file, a still image will be displayed.
Delete: Click Delete to delete the selected folder or file.
If you select a folder, any files in the folder will also
be deleted.
Refresh: Click Refresh to reload the latest data.
Recording target
Select the video codec mode you want to record.
For detailed settings of video codec mode, see the Video
codec tab in the Video / Audio menu.
Notes
• You can record still images even if the video is
specified with an image codec set to H.264.
• Image quality setting for a still image can be changed
only when the image codec is set to JPEG.
• If you want to change the image quality of recorded
still images, change the image codec to JPEG.
• A folder containing no still image files may appear.
Image file name
The file name consists of three parts: a prefix, a file
number and an extension.
Set the prefix of up to 30 alphanumeric characters. You
can include - (hyphen) and _ (underscore) in the prefix.
The file number and extension are assigned
automatically by the camera.
The file number consists of the year (4 digits), month (2
digits), date (2 digits), hour (2 digits), minutes (2 digits),
seconds (2 digits), and a sequential number (8 digits).
The Greenwich Mean Time will be used in the file name.
The extension is .jpg.
Edge Storage movie
Recording status
Display the current recording status.
The recording status will not be updated until the screen
is refreshed.
Use the Start Recording and Stop Recording button to
start or stop the recording manually.
Note
When recording manually, do not set Edge Storage
movie in the Execution Condition tab of the Action
output menu to Off.
