Administrating the Camera
Setting the Sensor input/Camera tampering detection/Motion detection — Action input Menu
45
OK/Cancel
See “Buttons common to every menu” on page 20.
Camera tampering detection Tab —
Set the camera tampering detection
Notes
• Before using the camera tampering detection function,
first adjust the focus* or the focus/zoom**.
If you adjust focus/zoom with the camera tampering
detection function activated, detection may not be
effective.
* Focus: SNC-VB635/VB630/VB600/VB600B/EB630/
EB600
** Focus/zoom: SNC-VM630/VM600/VM600B/
VM631/VM601/VM601B/VM632R/VM602R/EM630/
EM600/EM631/EM601/EM632R/EM602R
• Deselect the checkbox of Stabilizer in the Installation
tab of the System menu. After setting the camera
tampering detection, set the Stabilizer function again.
Enable
Select the checkbox to activate the function to detect
camera tampering, such as direction shifting or spray.
Detection status
Display the tampering detection state of the time when
Camera tampering detection tab is opened. To clear the
detection status, click Clear button.
OK/Cancel
See “Buttons common to every menu” on page 20.
Motion detection Tab — Set the
motion/VMF detection
Motion detection responds to moving objects in the
camera image and triggers an alarm.
In VMF, an alarm sounds when motion is detected under
the motion detection setting, entering or passing through
a specified area or inspection line. An alarm also sounds
when an object has been left or removed from a specified
area or inspection line.
The detected object will be displayed on the monitor in
the green frame. The removed object and left object will
be displayed in the magenta frame.
When you click the Motion detection tab, a dialog
appears. Enter the user name and password.
The factory setting of the user name and password for
the Administrator is set to “admin”.
For security, be sure to change the password from the
factory setting before using the camera.
Note
Perform the following before setting the motion
detection.
•Set Image size1 in the Video codec tab of the Video /
Audio menu or Video menu to the maximum rate.
• Deselect the checkbox of Image 1 in the PTZ control
tab of the PTZ control menu.
• Deselect the checkbox of Stabilizer in the Installation
tab of the System menu.
What is VMF
VMF is a function for detecting an object entering or
passing through a specified area or inspection line, or
when an object has been left or removed from a specified
area or inspection line. Video/audio recording and/or
audio file playback can be synchronized with this alarm.
You can set the inspection methods to execute
independently. Intrusion and Passing can also be set to
execute in combination.
For example:
• An alarm sounds when an object enters areas A, B and
C.
• An alarm sounds when an object passes through area
A and enters area B.
• An alarm sounds when an object passes through areas
A and B, and enters area C.
• An alarm sounds when an object enters area A, and
passes through area B.
Intrusion
When a moving object enters the designated area, an
alarm sounds.
Passing
A passage line is determined, and when a moving object
passes the setting line, an alarm sounds.
Left object
When a moving object has been left in the designated
area, an alarm sounds.
Removed object
When a moving object has been removed from the
designated area, an alarm sounds.
Notes
• Before actual use, perform an operation test and
confirm that the motion detection function works
correctly.
• Even when privacy masking is used, the motion
detection function operates based on the images
before masking is processed.
