21
Menu Configuration and Basic Menu Operations
Function menu displays
When “Operation” is selected
The settings on this display are displayed on the display
window block (page 13).
When “SW” is selected
When “WF/PIX Select” is selected
GammaECSShutter
Master Gain
0.45 0dB30.02000
Exit
ECS
Operation
SW
WF/PIX
Select
Ctrl
Shutter
ND
1 2345
EDCBA
CC
You may select the ND and CC filters
by pressing and highlighting these
buttons with [Ctrl] selected.
When [Ctrl] is not selected, the button
corresponding to the filter selected on
the camera is highlighted.
Press to return to the previously
selected menu.
Adjust each item using the corresponding
control knob.
These items can be adjusted either by turning the corresponding
control knobs or pressing v or V.
The value increases when v is pressed and decreases when V is
pressed. It continuously changes when either button is held down.
Press and highlight to enable
filter selection from this
display.
Black
Gamma
Satu
-ration
Knee
Aperture
Knee
Sat
5600K
Auto
Knee
Skin
Detail
Mono
Color
Contrast
Detail
Gate
Color
Correct
Operation
Exit
SW
1
2
/
WF/PIX
Select
Press either to flip the pages of the menu.
Press to return to the previously selected
menu.
Current page number/Total number of pages
(1/2 means that the SW menu consists of 2 pages in all
and that the first page of the menu is displayed at present.)
These buttons turn on and off the
corresponding functions.
The buttons whose designation includes
“Off” (such as [Knee Off] on page 2) turn
the respective functions OFF when
highlighted. Other buttons turn the
respective functions ON when
highlighted.
[5600K], [Auto Knee], and [Skin Detail]
operate in synchronization with the
corresponding camera/CCU function
buttons(see page 9).
Exit
WF/PIX
Select
Operation
SW
R
G B ENC
R G B SEQ ENC
PIX
WF
Press to return to the previously
selected menu.
You may select the monitor output
by pressing and highlighting these
buttons.
