9
HDC1500R/1400R/1500: HKC-HB15 Installed
signal from this connector is fed from the HD TRUNK
OUT connector of the camera control unit.
When using the camera in stand-alone status (no
camera control unit connected): The HD-SDI/VBS
input signal from this connector can be displayed on the
viewfinder as RET2. Select the input signal on the
<EXT RETURN> page of the MAINTENANCE
menu.
For applicable input signals, see “Format of the external
return signal input” (page 10).
• By changing the installation method, the connector can
be returned to the conventional PROMPTER 2
connector. For details, consult a Sony service or sales
representative. Note that it does not function as an HD
TRUNK IN connector in that status.
• The HD-SDI signal fed to this connector must be in
frequency synchronization with the camera.
• Signal selection is not possible when the camera is used
in a COAXIAL connection system (page 25) or Dual-
Camera system (page 26), as the connector is used for
connection to a camera control unit or connection
between the primary camera and secondary camera.
e SDI 2 connector (BNC type)
For HD-SDI or SD-SDI signal output.
Select the output signal with SDI-2 OUT on the <SDI
OUT> page of the MAINTENANCE menu. You can select
from among MAIN(HD-SDI), VF, RET, and SD-SDI.
LINK-B can also be selectable when the camera is used
with a Dual Link format.
For the signal settings, see “Video Formats and the Output
Signals of the Camera” (page 11).
f AUDIO IN CH2 switch
The AES/EBU setting is not valid in a Sub-Camera system
(page 27).
MAINTENANCE Menu
Parts of M12, M13 (HDC1400R only), and M19 are changed as follows, and the <EXT RETURN> page is added as M20.
Notes
Menu page No. Item⁄ Default Settings Remarks
<SDI OUT> M12
(U18)
SDI-1 OUT MAIN MAIN, LINK-A, HD
PROMPTER, 3G-SDI
MAIN: Displayed for Single
Link formats only
LINK-A: Displayed for Dual
Link formats only
(HDC1500R/1500 only)
SDI-2 OUT MAIN MAIN, VF, LINK-B, RET,
SD-SDI
LINK-B: Valid with Dual Link
formats only (HDC1500R/
1500 only)
SD-SDI: SD signal selected for
OUTPUT SIGNAL of
<DOWN CONVERTER>
(PWR SAVE) Displayed only when SDI-2
OUT is in POWER SAVE mode
CHARACTER OFF ON, OFF Not displayed if SDI-2 OUT is
set to VF or LINK-B
EMB AUDIO OFF ON, OFF
(1-MIC1 2-MIC2)
(3-AES1 4-AES2)
Displayed when SDI-2 OUT is
MAIN or LINK-B (display only)
(1-PGM1 2-PGM2)
(3-ENG 4-PROD)
Displayed when SDI-2 OUT is
VF, RET, or SD-SDI (display
only)
<POWER SAVE> M13
(U11)
SDI-2 OUT PWR SAVE PWR SAVE, ACTIVE As before (HDC1500R/1500
only)
DOWN CONVERTER ACTIVE PWR SAVE, ACTIVE As before
