29
h Gain value
Displays the video gain value (dB) set with the GAIN switch.
i Focus position
Shows the focus position of a zoom lens as a numeric value (0
to 255 (infinity)).
Note
Displayed only when a serial communication lens is
connected.
j Battery voltage
Displays the input voltage.
k Focus position meter marker name
Displays the marker name of the focus position meter.
l Setting change / adjustment process message area
This area is only used when the MESSAGE item of the menu
is set to other than OFF.
m F value
Indicates the lens F (iris opening) value.
n Shutter/ECS
Displays the shutter/ECS status. Nothing is displayed if the
electronic shutter is set to OFF.
When you press the CANCEL/STATUS switch
to STATUS
The status display is changed to show the following items.
a Assignable switch indicator
The function assigned to the assignable switch (page 10) is
indicated.
For the functions that can be assigned, see OPERATION
menu <SWITCH ASSIGN1> 15 (U09) (page 48).
b Format indicator
The current video format is displayed.
c ‘!’ display area
This area is used to display non-standard status, using the
<‘!’ IND> function. Display options can be set, using the menu.
For details, see OPERATION menu <‘!’ IND> 02 (U05)
(page 42).
d Light sensor level indicators
This area shows the light sensor levels in segments.
CAM T BPU: Light sensor level at the BPU connector
(page 11) of the camera
CAM t BPU: Light sensor level at the CAMERA connector of
the BPU
BPU T CCU: Light sensor level at the CCU connector of the
BPU
BPU t CCU: Light sensor level at the CAMERA connector of
the CCU
Note
If a camera control unit other than an HDCU2000/2500 is
connected, correct indications may not be obtained.
1080-59.94i
ASSIGNABLE :OFF
!ND :2
!CC :C
!FAN :MAX
!EXT :ON
OPT LV:
C
C
CAM
ssxxxxxxb
BPU
ssxxxxxxb
CCU
ssxxxxxxb
ssxxxxxxb
c
c
a
c
d
b
